R15ID3S-65EX
Informatica ATEX
13.3" (1920 x 1080) Resolution Transflective TFT-LCD Panel Intel® Core™ i5-7200U Defence Ultra Rugged Tablet EX Certificate: Class1, Division 2 & ATEX Zone 2 device certified for hazardous area application Fanless, streamlined enclosure for highly efficient heat dissipation Protection class IP65 all around incl. connectors Shock, vibration and drop protected (MIL-STD-810G) 5 wire Resistive Touch Screen (Explosion-proof) VESA Mount
01-Industrie-Panel-PC-R15ID3S-65EX
02-Industrie-Panel-PC-R15ID3S-65EX
03-Industrie-Panel-PC-R15ID3S-65EX
Numero Ordine:
23152541
prezzo lordo: € 0,00
Prezzo su richiesta
prezzo lordo: € 0,00
Prezzi più IVA più spese di spedizione
Tempi di consegna: su richiesta
SPEZIFIKATIONEN
| Numero Ordine: | 23152541 |
| Manufacturer: | WM |
| Matchcode manufacturer: | nein |
| Manufacturer: | Winmate |
| Manufacturer item number: | R15ID3S-65EX |
| dimensions width: | 39,6 |
| dimensions height: | 31,0 |
| dimensions depth: | 4,9 |
| Material housing: | Edelstahl / stainless steel |
| Material Front : | Edelstahl / stainless steel |
| protection front: | IP65 |
| colour: | Aluminium eloxiert / anodized aluminum |
| controls: | 2 Keys: Power, Reset |
| VESA-Mounting Interface: | VESA 100 x 100 mm |
| mounting: | Tragarm-, Standfuß-, Wandmontage / Suppo |
| cooling: | lüfterlos / fanless |
| Display-diagonal (inch): | 15,0 |
| aspect ratio: | 4:3 |
| resolution: | 1024 x 768 |
| brightness: | 550 cd/m² |
| contrast: | 2000:1 |
| Display-Technologie: | LCD, LED Backlight |
| Touch-Screen or glass: | 5 Wire Resistive |
| Touch Interface: | USB |
| Manufacturer controller: | Premier |
| voltage input DC: | 9-36 V/DC |
| external power supply: | 12 V/DC, 100 - 240 V/AC, 4-pin |
| USB: | 2 x USB 2.0 (M12 type) |
| serial: | 1 x RS-232 (M12 type) |
| LAN: | 1x RJ45 - 10/100/1000 Mbps (M12 type) |
| CPU Typ: | Atom |
| CPU Model: | N2600 |
| CPU 64bit: | Ja |
| CPU speed: | 1,6GHz |
| CPU cores: | 2 |
| CPU socket: | FCBGA559 |
| RAM size (MB): | 4096 |
| RAM Number of benches: | 1 |
| RAM Typ: | SO-DDR3L |
| RAM speed: | 1600 |
| CPU class: | Atom / Celeron |
| SSD design: | mSATA |
| SSD max. number: | 1 |
| SSD capacity (GB): | 128 |
| Ethernet connections: | 1 x RJ-45 |
| Ethernet data transfer: | 1 x Gigabit-LAN |
| Betriebssystem: | Optional |
| operating temperatur min.: | -20°C |
| operating temperatur max.: | 50°C |
| warranty: | 24 Monate / 24 months |
