Stainless steel Panel PCs and monitors – perfect for the food industry

With protection class IP65 to IP69K, the stainless steel Panel PCs and industrial monitors are perfectly suited for the food industry

Perfect for the food industry:
Multitouch PPCs + LCDs in stainless steel.

20.10.2020,

the food industry has high hygienic requirements and stressful cleaning procedures – a challenge for any IT hardware. TL’s stainless steel systems are an ideal choice here and are perfectly suited to control the processing of raw materials/ingredients, in the final packaging, or to ensure the quality and safety of the end product.

The housings made of SUS 316 / AISI 316 stainless steel are corrosion and liquid resistant. Type 316 steel is a chromium-nickel stainless steel containing between two and three percent molybdenum. The molybdenum content increases corrosion resistance – even in chloride solutions – and increases durability at high temperatures. Perfect for frequent cleaning and aggressive disinfection.

Discover Panel PCs >

Discover LCDs >

IP65 offers protection against water jets and is absolutely dustproof. You have the choice between different display sizes from 10,4" to 21,5".

The highest protection class IP69K allows easy cleaning and sterilization with up to 80 °C hot water and up to 30 bar pressure.

High-quality, resistant processing of brushed stainless steel

The PCAP Multi-Touch Screens with completely flat front surface without dirty edges are ideal for high hygienic requirements and frequent cleaning.

Stainless steel housing including all interfaces completely protected

The robust stainless steel housing is fully protected including all interfaces. The appropriate connection cables are included.

Emergency stop and flat button for control and signalling integrated in the Panel PC and monitor housing

Emergency stop and flat pushbuttons integrated in the robust and corrosion-protected stainless steel housing bring control and signalling directly into the working area.

Rotary switch at the front of the stainless steel Panel PC

The easy-grip rotary switch allows quick and easy switching between touch modes for hand, rain and glove operation. (optional other assignment)

Discover Panel PCs >

Discover LCDs >

Display:		10" / 15" / 19" / 21.5" projected capacitive multi-touch screen
CPU:		Celeron N2930 Core i5-7200U no (purely passive display)
OS:		Windows 10 IoT Enterprise
System memory:		4 GB / 8 GB DDR3
Storage:		from 64 GB SSD
WLAN:		optional
Interfaces:		2 × USB, 1 × COM, 1 × RJ45-Ethernet, CN1 + CN2 for front buttons control
Power:		9~36 V_DC
Protection class:		IP65 / IP69K
Material:		Stainless steel brush-finished, SUS 316 / AISI 316
Installation:		VESA interface at the rear

Our capability to provide delivery is as ever unrestricted.
You are welcome to make personal appointments with us in the form of Skype, video and telephone conferences.
All work processes are carried out digitally and – adapted to the situation – also locally in the home office.
