WM 17-IK70-CH
no Touch-Screen

Chassis-Panel-PC für den professionellen Einsatz
Panel-Industrie-PC in robustem Stahlblech-Gehäuse
Ausgelegt für industrielle Anwendungen im Dauerbetrieb
Einfache Installation mit rückseitiger VESA-Montageschnittstelle
Langzeitverfügbarkeit

01-Chassis-Industrie-Panel-PC-R17IK7T-CHM1
01-Chassis-Industrie-Panel-PC-R17IK7T-CHM1
13-Chassis-Panel-PC-Interfaces / TL Produkt-Welten / Panel-PC / Chassis (VESA-Mounting) / ohne Touch-Screen
13-Chassis-Panel-PC-Interfaces / TL Produkt-Welten / Panel-PC / Chassis (VESA-Mounting) / ohne Touch-Screen
15-Chassis-Panel-PC-Customized / TL Produkt-Welten / Panel-PC / Chassis (VESA-Mounting) / ohne Touch-Screen
15-Chassis-Panel-PC-Customized / TL Produkt-Welten / Panel-PC / Chassis (VESA-Mounting) / ohne Touch-Screen
01-Chassis-Industrie-Panel-PC-R17IK7T-CHM1
01-Chassis-Industrie-Panel-PC-R17IK7T-CHM1
Numero Ordine: 23171532
prezzo lordo: € 0,00
Prezzo su richiesta

Prezzi più IVA più spese di spedizione

Tempi di consegna: su richiesta

HIGHLIGHTS
  • robustes Stahlblech-Chassis
  • VESA-Montageschnittstelle
  • P-CAP / Resistiver Touch-Screen optional
  • Langzeitverfügbarkeit
Scarica scheda tecnica in PDF

SPEZIFIKATIONEN
Numero Ordine: 23171532
Manufacturer: WM
Matchcode manufacturer: nein
Manufacturer: Winmate
series name: SlimLine-Serie
Manufacturer item number: R17IK7T-CHM1
mechanics: Chassis (VESA-Mounting)
dimensions width: 39,4
dimensions height: 33,2
dimensions depth: 7,4
Material housing: Stahlblech / steel sheet
Material Front : Stahlblech / steel sheet
protection front: IP54
protection device: IP20
colour: RAL 9004 / signal black
controls: 2 Keys: Power, Reset
VESA-Mounting Interface: VESA 75 x 75 mm, 100 x 100 mm
mounting: Tragarm-, Standfuß-, Wandmontage / Support arm, stand, wall mount
cooling: aktiv / fan cooling
Display-diagonal (inch): 17
aspect ratio: 4:3
resolution: 1280 x 1024
brightness: 350 cd/m²
contrast: 1000:1
Display-Technologie: LCD, LED Backlight
Touch-Screen or glass: Schutzglas / protective glass
voltage input DC: 12 V/DC
voltage input AC: 110 - 240 V/AC
external power supply: 12 V/DC, 100 - 240 V/AC, 4-pin
input: 93 Watt
HDMI: 1 x HDMI (optional)
DisplayPort: 1 x DisplayPort
USB: 4 x USB 3.0
serial: 2 x RS-232, 1 x RS232/422/485
Audio: Mic-In, Line-Out
LAN: 2x RJ45 - 10/100/1000 Mbps
Mainboard form factor: Mini-ITX
chipset: Intel Q170
CPU Typ: Core i3
CPU Model: 7100T
CPU 64bit: Ja
CPU speed: 3,4 GHz
CPU cores: 2
CPU socket: LGA1151, H4
RAM size (MB): 4096
RAM max. size (MB): 16384
RAM Number of benches: 1
RAM Typ: SO-DDR4
RAM speed: 2400
Grafik Controller: Intel HD Graphics 630
Audio Controller: Realtek ALC283 HD Codec
safety: TPM 2.0
CPU class: Core i3 / i5 / i7
CPU alternative option 1: Core i3-7xxx
CPU alternative option 2: Core i5-7xxx
CPU alternative option 3: Core i7-7xxx
HDD design: 2,5"
HDD connection: SATA
HDD capacity (GB): 500
MiniPCIe Slot SSD : 1
SSD design: M.2
SSD capacity (GB): 256
RAID-System: Nein / no
CD/DVD-Writer : Nein / no
Ethernet connections: 2 x RJ-45
Ethernet data transfer: 2 x Gigabit-LAN
Ethernet Controller : Intel I211IT + I219LM
MiniPCIe Slot WLAN/WWAN : 1
WLAN : Optional / optional
Bluetooth : Nein / no
camera: Nein / no
Barcode Scanner: Nein / no
RFID Reader : Nein / no
operating system: Windows 10 IoT Enterprise
operating-system language version: deutsch / english / italian
operating-system support: Windows 10 IoT
operating temperatur min.: 0°C
operating temperatur max.: 50°C
warranty: 24 Monate / 24 months
